TAIHO Rice Observation Pro Series

Cooperating with tens of thousands of customers, intelligent interconnection, worry-free after-sales Nearly a thousand process quality inspections, consistent quality, and excellence Hundreds of algorithms have been developed to identify colors and shapes Twenty years of deep cultivation in color sorting, and doubled production

Name：

6SXM-270V+Pro 6SXM-450V+Pro 6SXM-630V+Pro 6SXM-720V+Pro 6SXM-900V+Pro 6SXM-1080V+Pro 6SXM-1440V+Pro

Online contact +86 182 2585 8868

Scope of application Product advantages Specifications and Parameters

Scope of application

Red rice

Brown rice

Indica rice

Polished round-grained rice

Polished glutinous rice

Product advantages

Twenty Years Of Deep Cultivation In Color Sorting, Doubled Production

Twenty years of deep cultivation in color sorting, both internal and external improvements, and doubled production. With new evolution, improved efficiency and increased production, platform-based models, upgraded modular structure, load increased by 3-5 times, feeding and rejection system efficiency increased by 30%, dust removal optimized by 50%, and production increased by 66%.

Hundreds Of Algorithms To Identify Colors And Shapes

Hundreds of algorithms have been developed to identify colors and shapes. Shape and color selection by AI empowerment, intelligent system, identification as fine as 0.15mm, 350 million pixels ultra-clear resolution, new shape selection algorithm for yellow, white, transparent, long, round, and broken materials.

Thousand Process Quality Inspections, Consistent Quality

Nearly a thousand process quality inspections, consistent quality, and excellence. Thousands of quality inspections, quality control, standardized production, more stable equipment effects, SOC smart core matching intelligent high-frequency solenoid valve, blowing thousands of times per second, lower carry-out, higher clean rate.

Cooperating With 10000+ Customers, Worry-Free After-Sales

Cooperating with tens of thousands of customers, intelligent interconnection, worry-free after-sales. We are listed brand with strong strength, we offer customized service 24/7 online, and real-time response in the cloud. Including user profile creation for tracking service, equipment can be intelligently interconnected to achieve remote operation and maintenance.

Specifications and Parameters

Model	Single-channel throughput (t/h)	Power (kw)	Supply voltage (v)	Air pressure (mpa)	Air consumption (m ³/min)	Size (mm)	Weight (kg)
6SXM-270V+Pro	≤3.0	2.4	AC220V±5% 50/60Hz	0.5-0.8	＜2.5	1736*1510.1945	1020
6SXM-450V+Pro		3.9	AC220V±5% 50/60Hz	0.5-0.8	＜4.0	235115101945	1335
6SXM-630V+Pro		5.3	AC220V±5% 50/60Hz	0.5-0.8	＜5.5	285415101945	1715
6SXM-720V+Pro		6.0	AC220V±5% 50/60Hz	0.5-0.8	＜6.0	316815101945	1910
6SXM-900V+Pro		7.4	AC220V±5% 50/60Hz	0.5-0.8	＜7.0	379615101945	2240
6SXM-1080V+Pro		8.9	AC220V±5% 50/60Hz	0.5-0.8	＜8.0	443415101945	2655
6SXM-1080V+Pro (back to back)		9.4	AC220V±5% 50/60Hz	0.5-0.8	＜8.0	282229011940	2735
6SXM-1440V+Pro (back to back)		12.2	AC220V±5% 50/60Hz	0.5-0.8	＜10.0	345029011940	3505

Note:

1. All color-sorting performance metrics are based on rice containing ≤5% impurities.

2. Product configurations are continuously updated; specifications may differ across production batches. The actual machine takes precedence.

3. Performance data in this brochure are derived from controlled tests; on-site results may vary due to environmental factors.
