Scope of application
Walnut
Nut kernels
Product advantages
New Track 3.0

Remote identification: The remote sorting system effectively reduces dust and debris, resulting in clearer identification;

Anti damage system: Anti damage 3.0, effectively reducing material damage;

New industrial machinery structure: Industrial machinery structure 3.0, compact size, waterproof and durable; 304 stainless steel structure, wire drawing process, overall bright and beautiful.


Intelligent selection recognition

Holographic flash camera: 350 million pixels+curved self repairing lens, with higher material recognition accuracy;

Al Smart Core Processing Platform: Equipped with SOC Smart Core and integrating Al deep learning algorithms, it is faster and more intelligent.


Quality and Wisdom Exclusion

Exclusion system: High end customized solenoid valves equipped with center positioning algorithm for precise elimination;

Sorting system: Long distance conveying setting, stable conveying trajectory, more uniform distribution, and better color selection effect.


Outstanding output

Full coverage ash cleaning system: rodless cylinder, strong toughness without deformation, smoother ash cleaning;

Uniform feeding system: High frequency vibration system, with uniform feeding distribution and no stacking.



Fully intelligent interconnection

Zhi Jian Ul: Minimalist interface, simple debugging, and convenient operation;

Intelligent sorting: Intelligent sorting+visual operation, simpler to use;

Intelligent linkage control: Global intelligent interconnection, real-time sharing of color selection schemes.



Specifications and Parameters

Model

Throughput

(t/h)

Power

(kw)

Electricity voltage

(v)

Air pressure

(mpa)

Air consumption

(m³/min)

Size

(mm)
Weight
(kg)
6SXZ-600KD2Y 3.0-5.0 3.6 AC380±10% 50/60Hz 0.5-0.8 <1.0 1889*3564*1855 1150
6SXZ-1200KD2Y 6.0-13.0 4.4 AC380±10% 50/60Hz 0.5-0.8 <2.0 2489*3564*1855 1490
6SXZ-1800KD2Y 8.0-15.0 5.5 AC380±10% 50/60Hz 0.5-0.8 <3.0 3089*3564*1855 1805
6SXZ-1200KS2Y 7.0-14.0 8.0 AC380±10% 50/60Hz 0.5-0.8 <4.0 2489*3564*2405 2540
6SXZ-1800KS2Y 12.0-20.0 9.7 AC380±10% 50/60Hz 0.5-0.8 <5.0 3089*3564*2405 3080


Note:


1. All the above color sorting performance data are based on peanuts with impurity content below 5%.

2. Custom motor vibrators can be optionally equipped according to material sorting needs; please consult the sales staff for details.

3. Product configurations are constantly updated. Parameters may vary for products of different periods; please refer to the actual machine for details.

4. The performance shown in this brochure is based on test results and may differ in actual production due to varying on-site conditions.
