Flexible soft materials, material transfer by pressing, better flat throwing posture, 360 ° realistic reproduction, and more accurate recognition.
New structural design, enjoying a large space, more uniform material distribution, and no longer having the risk of material blockage.
Shelled peanut
Peanut fruit
Sunflower seed
Beans
Corn
Dried chili peppers
Pepper
Zanthoxylum bungeanum
Various types of traditional Chinese medicine
Pine nut
Almond
Almond shell
Semen ziziphi spinosae
Cashew
Raisins
Rose
Garlic
Dehydrated garlic slices
|
Model |
Throughput
(t/h) |
Power (kw) |
Electricity voltage (v) |
Air pressure (mpa) |
Air consumption (m³/min) |
Size (mm) |
Weight (kg) |
| 6SXZ-600KD2Y | 3.0-5.0 | 3.6 | AC380±10% 50/60Hz | 0.5-0.8 | ＜1.0 | 1889*3564*1855 | 1150 |
| 6SXZ-1200KD2Y | 6.0-13.0 | 4.4 | AC380±10% 50/60Hz | 0.5-0.8 | ＜2.0 | 2489*3564*1855 | 1490 |
| 6SXZ-1800KD2Y | 8.0-15.0 | 5.5 | AC380±10% 50/60Hz | 0.5-0.8 | ＜3.0 | 3089*3564*1855 | 1805 |
| 6SXZ-1200KS2Y | 7.0-14.0 | 8.0 | AC380±10% 50/60Hz | 0.5-0.8 | ＜4.0 | 2489*3564*2405 | 2540 |
| 6SXZ-1800KS2Y | 12.0-20.0 | 9.7 | AC380±10% 50/60Hz | 0.5-0.8 | ＜5.0 | 3089*3564*2405 | 3080 |
Note:
1. All the above color sorting performance data are based on peanuts with impurity content below 5%.
2. Custom motor vibrators can be optionally equipped according to material sorting needs; please consult the sales staff for details.
3. Product configurations are constantly updated. Parameters may vary for products of different periods; please refer to the actual machine for details.
4. The performance shown in this brochure is based on test results and may differ in actual production due to varying on-site conditions.
|
Model |
Throughput
(t/h) |
Power (kw) |
Electricity voltage (v) |
Air pressure (mpa) |
Air consumption (m³/min) |
Size (mm) |
Weight (kg) |
| 6SXZ-600KD2Y | 3.0-5.0 | 3.6 | AC380±10% 50/60Hz | 0.5-0.8 | ＜1.0 | 1889*3564*1855 | 1150 |
| 6SXZ-1200KD2Y | 6.0-13.0 | 4.4 | AC380±10% 50/60Hz | 0.5-0.8 | ＜2.0 | 2489*3564*1855 | 1490 |
| 6SXZ-1800KD2Y | 8.0-15.0 | 5.5 | AC380±10% 50/60Hz | 0.5-0.8 | ＜3.0 | 3089*3564*1855 | 1805 |
| 6SXZ-1200KS2Y | 7.0-14.0 | 8.0 | AC380±10% 50/60Hz | 0.5-0.8 | ＜4.0 | 2489*3564*2405 | 2540 |
| 6SXZ-1800KS2Y | 12.0-20.0 | 9.7 | AC380±10% 50/60Hz | 0.5-0.8 | ＜5.0 | 3089*3564*2405 | 3080 |
Note:
1. All the above color sorting performance data are based on peanuts with impurity content below 5%.
2. Custom motor vibrators can be optionally equipped according to material sorting needs; please consult the sales staff for details.
3. Product configurations are constantly updated. Parameters may vary for products of different periods; please refer to the actual machine for details.
4. The performance shown in this brochure is based on test results and may differ in actual production due to varying on-site conditions.
