Recycled Plastic Color Sorter (UV Series) - Hefei Taihe Intelligent Technology Group Co., Ltd

Recycled Plastic Color Sorter (UV Series)

The recycled plastic color sorter (UV series) is equipped with nano level ultra clear sensors, effectively identifying fluorescent and aging films in bottle slices that are difficult to recognize by the naked eye, with a recognition accuracy of up to 0.3mm, easily removing small impurities; Improve the purity of AAA grade bottle slices to meet the higher standards of high-quality bottle slice sorting required by processing enterprises.

Fluorescent and aging film sorting Improve the purity of AAA grade bottle tablets Nano level ultra clear sensor

Name：

6SXG-315ZW

Online contact +86 178 5515 2143

Scope of application Product advantages Specifications and Parameters

Scope of application

Fluorescent PVC rosin

Bottle aging material

Product advantages

Multidimensional four view recognition system

Integrating a four view holographic camera with 350 million pixel ultra clear resolution, achieving 360 degree three-dimensional imaging, effectively identifying fluorescent and aging films in bottle films.

UV optical sensing system

Matched with high brightness ultraviolet LED light source, multi angle illumination, fluorescent and aging film with exquisite appearance: Matched with AI color restoration technology, self correction and color correction, high restoration and ultra fidelity.

Fully enclosed zero light sensing system

Fully enclosed and opaque design, with innovative zero light sensing technology, the internal optical sensing system remains stable regardless of changes in the external lighting environment.

Efficient water-cooled heat dissipation system

Adopting a strong water-cooled circulating heat dissipation device, it has fast heat dissipation, low noise, and low energy consumption; Efficiently ensuring the continuous and stable operation of ultraviolet LED light sources and holographic flash cameras.

Intelligent Variable Frequency Blowing System

Equipped with intelligent variable frequency electromagnetic valve, 13 billion times of long-term spraying, no air leakage, low power consumption; Applied adaptive injection technology, with a fast response of 0.05 milliseconds, no exhaust gas, and low discharge.

Three pollution dust removal and purification system

Full coverage gradient air purification, complete filtration of water, oil, and dust, without omission or pollution; Self collaborative cleaning technology, real-time induction cleaning, zero delay, and cleaner.

Specifications and Parameters

Model

Throughput

(t/h)

Sorting accurancy ratio

(%)

Power

(kw)

Supply voltage

(v)

Air pressure

(mpa)

Air consumption

(m³/min)

Size

(mm)

Weight

(kg)

6SXG-315ZW

1.5-2.5

≥98

5.1

220V/50Hz

0.5-0.8

1.8-2.2

2500*1618*2075

1453

Note:

1. The above color selection performance takes PET with impurities ranging from 1% to 15% as an example;

2. If there are any updates to the product, the actual machine shall prevail.

Model

Throughput

(t/h)

Sorting accurancy ratio

(%)

Power

(kw)

Supply voltage

(v)

Air pressure

(mpa)

Air consumption

(m³/min)

Size

(mm)

Weight

(kg)

6SXG-315ZW

1.5-2.5

≥98

5.1

220V/50Hz

0.5-0.8

1.8-2.2

2500*1618*2075

1453

Note:

1. The above color selection performance takes PET with impurities ranging from 1% to 15% as an example;

2. If there are any updates to the product, the actual machine shall prevail.
